• Applicable for SOC(splicer on connector)
• Smallest, Lightest, Fastest
• Most Reasonable Price ver Best Quality
• Resistance to Shock, Rain, Dust, 100% Proven by Field Test
• Efficient Two Heater System
Specifications Splicers Ilsintech Swift F1
| Fiber Alignment | Fixed V - Groove(Clad to Clad) |
| Size of Clad | 125um |
| Size of Coating | 250 ~ 900um |
| Aver Loss Ratio | 0.03dB(SM), 0.02dB(MM), 0.06dB(NZDS, DS) |
| Splicing time | 7sec |
| Heating sleeve | 20sec(0.9mm ), 70Sec(Indoor, 3.0mm) |
| Length of Sleeve | 60mm/40mm |
| Strength of Tensile | 1.96N |
| Storage of Data | 2,000 |
| Applicable cable | 0.25mm, 0.9mm, 2.0mm, 3.0mm, Indoor Cable |
| Size | 140(W) x 179(L) x 87(H) mm |
| Weight | 1.2 Kg (Include Rubber, Battery 2ea) |
| Power | DC Li-Polymer Battery, 100~240V AC Adapter |
| External Power | DC 12V appicable for Car Cigar Jeck |
| Capacity of Battery | 1400 mAh x 2 |
| Life time of Battery | Typical 140 cycles(0.9mm fiber) |
| Operating Temperature | -10C~ 50C |
| Storage Temperature | -40C~ 80C |
