Special features
• 16 Channels
• 12.5/25kHz Channel Spacing
• PL/DPL .
• 2 programmable quick access buttons
• More than 8 hrs talk time @ 5-5-90 duty cycle
• Battery Saver Mode
• High/Low Transmit Power Selection
• Low Battery Indicator
• Priority Scan
• Nuisance Channel Delete
• Repeater/ Talk around
• Monitor/Stick Permanent Monitor
• Button Lock
• Busy Channel Lockout
• Volume Set
• Time out timer (10-600 secs)
• Tight/ Normal Squelch Selection
|
General specification |
VHF |
UHF |
||
|
Frequency Range |
136-150MHz |
403-425MHz |
||
|
Storage channel |
16 |
|||
|
Channel Spacing |
12.5/25 kHz ( Switchable) |
|||
|
Operating Temperature |
-30℃ to +60℃( wireless transceiver) |
|||
|
|
-20℃ to +60℃(with NiMH battery) |
|||
|
Dimension(H×W×D) |
107mm×58mm×37mm |
|||
|
Weight |
350g |
|||
|
Battery life expectancy @5-5-90% work cycle |
>8 hours |
|||
|
Seal |
Through the rain IPX4 test |
|||
|
Impact and vibration |
Impact resistance polycarbonate chassis through the EIA 603 B testing |
|||
|
Dust and humidity |
Dust/moistureproof chassis through the EIA 603 B testing |
|||
|
Transmitter |
VHF |
UHF |
||
|
RF Output |
High Power |
Low Power |
High Power |
Low Power |
|
Stray and harmonic |
-63dBc(-26Bm@5W:-27dBm@4W) |
|||
|
Frequency Stability |
±2.5ppm |
|||
|
FM Noise |
40dB |
|||
|
Modulation Limited |
<=5Khz(25KHz) |
|||
|
Audio Frequency Response (6dB/octpre-emphasis,300-3000Hz) |
+1/-3dB |
|||
|
Audio distortion @ 1 kHz audio,60% maximum rated migration |
<5% |
|||
|
Receiver |
VHF |
UHF |
||
|
Receiving Sensitivity (12dB SINAD) |
<-119dBm(0.25μV) |
<-117.5dBm(0.3μV) |
||
|
Adjacent channels choice |
65dB(25kHz)、60dB(12.5kHz) |
|||
|
Intermodulation |
65dB(25kHz)、60dB(12.5kHz) |
|||
|
Spurious Signals |
65dB |
|||
|
Audio Distortion |
<5% |
|||
|
Noise |
40dB |
|||
|
Conducted Emission |
<-57dBm |
|||
|
Audio output @ < 5% distortion |
500mW |
|||
