• High sensitivity, multi output power
• Multi wavelengths optional, up to four wavelengths on two ports
• Automatic power-off, off time setting range 30~90mins
• Low battery alarm
• LCD display
• New-type conductive rubber switch, suitable for different operation environments.
Specifications
|
SAT-3E series Models |
|||||||
|
Model |
3E13 |
3E14 |
3E15 |
3E16 |
3E17 |
3E18 |
3E19 |
|
Working Wavelength(nm) |
1310/1550 |
650/1310/1550 |
850/1310/1550 |
850/1300 |
1490/1310/1550 |
1625/1310/1550 |
850/1300/1310/1550 |
|
Output Power (dBm) |
1310/1550: 0, -3, -6; 650: >0; 850/1300/1490/1625: -6 (error:±0.2) |
-6 (error:±0.2) |
|||||
|
Output Tone |
850/1300/1310/1550 /1490/1625: CW, 270Hz, 1KHz, 2KHz; 650: CW |
||||||
|
Spectrum Width |
≤ 5 nm |
||||||
|
Output Stability |
±0.03dB/15min; ±0.05dB/8h |
||||||
|
Optical Identifying Distance |
5km; 10km /15km optional (650nm) |
||||||
|
Display |
LCD |
||||||
|
Power-off Time |
30~99mins or none |
||||||
|
Optical Interface |
FC, SC, ST |
||||||
