Key Features
• Wide dynamic range, up to 30dBm
• Multi display units: nW, uW, mW, dBm, dB
• Automatioc turn-off, off time setting range 5～60mins
• Automatic zero clearing
• Low battery alarm
For model SAT-4E11, SAT-4E12, SAT-4E13, more functions are added
• Automatic frequency detection: 270Hz, 1kHz, 2kHz
• Data storage up to 1000 items; enables data transfer to PC via RS232
• Self-calibration function
• Real-time data monitoring function by PC
Specifications
|
Parameters |
Unit |
Technical index |
|||||
|
Model |
|
SAT-4E01 |
SAT-4E02 |
SAT-4E03 |
SAT-4E11 |
SAT-4E12 |
SAT-4E13 |
|
Detector |
|
InGaAS |
|||||
|
Wavelength |
|
800 ～ 1700 |
|||||
|
Working Wavelength |
nm |
850, 980, 1300, 1310, 1490, 1550, 1625 |
|||||
|
Dynamic Range |
dBm |
-70～+10 |
-50～+26 |
-50～+30 |
-70～+10 |
-50～+26 |
-50～=30 |
|
W |
0.1nW～10mW |
10nW～400mW |
10nW～1W |
10nW～10mW |
10nW～400mW |
10nW～1W |
|
|
Measurement Accuracy |
|
±5% |
|||||
|
Optical Interface |
|
FC, ST, SC; MU/LC (4E1X optional) |
|||||
|
Resolution |
|
dBm; 0.01dBm W: (0.1～1)% |
|||||
|
Power Supply |
|
2 X 1.5V alkaline cells |
|||||
|
Power-off Time |
|
None or 50～60 minutes adjustable |
|||||
|
Power Consumption |
mW |
30 |
|||||
|
Working temperature |
oC |
-10～+50 |
|||||
|
Storage Temperature |
oC |
-40～+70 |
|||||
|
Dimension |
mm |
140 x 72 x 38 |
|||||
|
Weight |
Kg |
0.25 |
|||||
