Based on the award winning JDSU MTS-8000 platform covering installation, maintenance and troubleshooting testing needs of any optical networks, the MTS-8000 V2 meets next generation network challenges with additional fiber inspection & test, ROADM and 40G / 100G test capabilities.

Features MTS-8000
• 10.4 inch high-visibility touch screen display
• High-speed PowerPC processor, rugged SATA solid-state hard disk and latest high-capacity Li Ion battery technologies
• 1G Ethernet, Wireless connectivity (3G, Wifi, Bluetooth) and four USB interfaces
• Built-in optical options including power meter, VFL and talk set
• Automated connector inspection with IEC pass/fail analysis
• Compatible with T-BERD/MTS-6000 test modules

Applications
• Enables optical connector inspection and full fiber characterization with OTDR, IL, ORL, CD, PMD and AP
• Tests and troubleshoot WDM systems and ROADM networks with Optical Spectrum Analyzers.
• Tests and troubleshoots converged Ethernet/IP networks at 10 Mbps to 100 Gpbs interfaces and captures and analyzes packets
• Tests Layer 1-3 Ethernet/IP SLAs with an automated, enhanced RFC 2544/SAMComplete per ITU-T Y.1564.
• Tests TDM/PDH to SONET/SDH at OC-3/STM-1 to OC-192/STM-64, including service disruption measurements and path overhead (POH) capture with triggers
• Measures PMD on live traffic and tests in-band OSNR in DWDM/ROADM systems with In-Service PMD
• Enables installation and maintenance of OTN networks up to 11.1 Gbps and OTU4 with full 100 Gpbs client .
• Supports 1/2/4/8/10 Gpbs FC for installation and maintenance of SANs and low-latency circuits

Specifications MTS-8000

OTDR Module	Central  wavelength	Pulse width	Dynamic range	Event  dead zone	Attenuation  dead zone
Short range  multimode (SRL)	850/1300±20nm	3 ns to 300 ns	24/24dB	0.5m	2m
Short range multimode  and singlemode (SRL)	850/1300/1310/ 1550/1625 ±20nm	3 ns to 20 us	24/24/ 40/38/37 dB	0.5 m (multimode) 0.8m (multimode)	5 m (multimode) 8 m (multimode)
Very short range  singlemode (VSRe)	1310/1550±20nm	10 ns to 10 us	32/30dB	2m	8m
Short range  singlemode (SRe)	1310/1550±20nm	10 ns to 10 us	34/32dB	3m	25m
Medium range  singlemode (MR)	1310 ±20nm  1490 ±15nm 1550 ±20nm 1625 ±10nm	3 ns to 20 us	40 dB 40 dB 38 dB 37 dB	0.8m	4m
Long range  singlemode (LR)	1310 ±20nm  1490 ±15nm 1550 ±20nm 1625 ±10nm	3 ns to 20 us	43 dB 40 dB 41 dB 41 dB	0.8m	4m
Very long range  singlemode (LR)	1310 ±20nm  1383 ±2nm 1490 ±15nm 1550 ±20nm 1625 ±10nm	3 ns to 20 us	45 dB 44 dB 42 dB 43 dB 43 dB	0.8m	4m
Ultra long range  singlemode (UHD)	1310/1550±20nm 1625±10nm	10 ns to 20 us	45.5/50dB 45.5dB	4.5m	15m
